Aerofy HD2 - Water Drainage

9
Water Drainage
Hold both sides of the water tank, and pull it out slowly.
Remove the water tank:
First take out the water tank(See Fig.1), and then firmly connect the drain
hose(Inner diameter 9.5mm/0.37inch) to the drain outlet(See Fig.2), and
connect the other end of the water hose to the floor drain or other
containers(See Fig.3), and finally put the water tank back.
Fig.1 Fig.2
Fig.3 Fig.4
・The unit adopts a non-contact water level switch. Remove the water tank while
the unit is running, the unit will stop working.
・Please do not remove the float in the water tank(See Fig.4). If it is removed, the
full water sensor will not be able to sense the water level, so that the unit is in a
full water state and cannot work.
・When putting it in the water tank, press the water tank tightly with both hands.
If the water tank is not put in place, the water full sensor will still alarm and the
dehumidifier will not work.
NOTE:
Water Tank
Continuous Drainage
