SECTION 1: FEATURES
1. All wetted parts are stainless steel, including the propeller.
2. The CLASS I model is available from 2-10 horsepower (1.5 - 7.5kW) in 60 Hz and 2 -
7.5 horsepower (1.5 – 5.6kW) in 50 Hertz. Similar models available from 15-40
horsepower (11- 30kW), and 50 - 100 horsepower (37.5 - 75kW).
3. The aerator operates with no splashing or spraying. All mixing and oxygen transfer
takes place under the water's surface.
4. Units can be operated alone or in groups to create a circular flow pattern.
- 2 -
FIGURE 1:
Construction features of the Class I TORNADO
®
aerator
Stainless Steel
Propeller
Grease zerks (easy to
reach)
Standard
Coupling
Flanges
Standard TEFC
Motor
Large open Propeller Hub
for more air flow
