FIGURE 5:
TORNADO Float Mount
SECTION 5: TORNADO AERATOR ACCESSORIES
AEROMIX offers a number of optional items including mounting accessories, mooring
accessories and electrical accessories. Unless ordered with the aerator, these
accessories are normally not included. The following drawings are general
arrangements and are not a detailed representation of offered accessories. For exact
drawings and parts lists, refer to the attachments to this manual, and the manual for the
float systems.
5.1: MOUNTING ACCESSORIES
The float mount and fixed mount (wall or bridge) are the two basic methods for
mounting the TORNADO aerator. The float mount (FIGURE 5) is best suited for large
basins, basins with sloped sides and basins with fluctuating water levels. It can be
easily moved to different locations.
FIGURE 6 shows a typical wall mount which is custom designed and built to wall and
water level dimensions supplied by the customer. These fixed mounts can be further
customized to allow swiveling the aerator and its mounting cradles through a full 180º
sweep, allowing fine-tuning of the direction of the mixing energy.
(Not shown, but also available, are mounting brackets that adapt our TORNADO aerator
to the float systems of other aerator
manufacturers.)
-5-
FIGURE 6:
TORNADO Wall Mount
