AIB-SO21/AIB-SO31/AIB-SN31/AIB-SN41 User Manual 19
◼ Front Panel Connector
Pin #
Definition
Pin #
Definition
1
Power On
2
GND
3
Reset
4
GND
5
Recovery
6
GND
7
Sleep
8
GND
9
LED＋
10
LED－
◼ SPI Connector
Item
Description
Location
CN1
Type
2*5P P:2.0mm H:7mm Wafer connector
Item
Description
Location
CN12
Type
2*5P P:2.0mm H:7mm Wafer connector
