AIB-SO21/AIB-SO31/AIB-SN31/AIB-SN41 User Manual 21
Pin #
Definition
1
Debug_UART_RX
2
Debug_UART_TX
3
GND
◼ Auto Power ON (APO) Switch
Position
Function
ON
Disable APO
1 (Default)
Enable APO
◼ 5V Fan Connector
Item
Description
Location
SW1
Type
DIP Switch
Notes
To enable APO function by Switch
Item
Description
Location
J8
Type
1*4P 1.25mm Wafer connector
