built with this feature (all Rubicons), removal of the
module will constantly illuminate the “Sway Bar” lamp
on the dash. For vehicles that were built without this
feature, addition of the module will not by itself enable
the system. For either circumstance, the AEV ProCal can
activate or deactivate the ASBS.
Note: Installing or removing the module must be done
prior to using the ProCal Module.
THROTTLE TOLERANCE PROGRAMMING MODE
Description: This mode allows the user to program
throttle tolerance and effectively pair a PCM and
pedal. When a new PCM or pedal has been installed,
the previous values stored in the PCM may not match
the specic tolerance of the pedal and need to be
reprogrammed.
Notes:
• This mode requires simultaneous inputs from
a user on the throttle pedal as well as the
multifunction light stalk. When programming,
follow the steps in a deliberate, but not rushed,
manner. The entire process should take
approximately 2-3 seconds. If the process is
completed either too fast or too slow, the pairing
will fail.
• The vehicle will honk once in the middle of the
process, and twice when nished. If the vehicle
has honked twice before you are nished try to go
a little faster and vice versa.
• The timing and process take about the same
amount of time to say as it does to actually do:
“Pedal Forward, Stalk Forward, Pedal Back, Stalk
Back”
Instructions:
1. Set the switches on the ProCal.
2. Turn the ignition to “RUN”, two clicks of the key.
