Instructions: Same as any other programming mode.
Turn the vehicle’s ignition to RUN, set the switching
according to the value above, and insert the module.
Restore may take a few seconds longer than other
programming modes. The horn will honk three times on
successful completion.
TROUBLESHOOTING
On occasion, the ProCal module may be unable to
complete a desired request for a variety of reasons,
including network errors, an invalid DIP switch setting, or
a prohibited request. For example, if a user tries to set a
TPMS low pressure threshold on a 2007 JK Wrangler, the
module will abort and present an error code because the
2007 JK Wrangler does not have TPMS.
When in an error state, the ProCal module will ash a
sequence on the dashboard of the vehicle, usually on the
vehicle’s theft system indicator (this is most commonly a
red LED above the coolant gauge in the cluster). This is
a two stage display, where a sequence is ashed once,
followed by a short pause, then another sequence, and
nally a longer pause and the code will repeat. Simply
count the two sequences and refer to the list below. For
example, if using an improper DIP switch combination the
user may see 4 ashes followed by a short pause, then
6 more ashes, a longer pause and the sequence will
repeat. This would be a 4-6 error.
