8 RE-50-RE-75-OI-vers. 2.6 gb 28.07.14
Module designation
1 Servo-drive with gearing
2 Encoder casing
3 Rotary flange
4 Encoder connection
5 Proximity switch
6 Motor connection
7 Mounting holes on the rear (see dimensions drawing)
Figure 1: Module designation
The RE rotary module consists of the servo-drive with gearing (1) with integrated
electric motor.
2.1.3 Mounting, Connection
Due to the rotating movement of the rotary flange garments,
hair or other materials may be caught and drawn into the sys-
tem while the module is being operated.
Caution: Commissioning may only be executed by qualified
personnel.
