10
Product description
EN
DTA 10
4.5 Approvals, conformities, certifications
The product complies with:
• EMC Directive (2014/30/EU)
• RoHS Directive (2011/65/EU)
4.6 Technical data
Parameter Value
General specifications
Dimensions housing (W x H x D) 100 x 188 x 65 mm
Measuring line PVC hose 4 x 1 mm
Length 20 m
Bottom part stainless steel
Housing material Wall mounting housing made of
impact-resistant plastic (ABS)
Measuring accuracy ± 3.0 cm (liquid column)
Function Push-to-Read level measurement
Display Multi-coloured, backlit graphical dis-
play (30 x 50 mm)
- Blue = Operation
- Red = Alarm
- Green = Parameterisation
Volume indication in litres (5 digits),
in % and liquid level in cm
Operating temperature range
Ambient 0/50 °C
Storage -20/65 °C
Medium 0/50 °C
Supply voltage
Nominal voltage 9 V monobloc battery
