© Copyright LOTRONIC 2016 BEAM1R Page 11
75
GOBO 2 SHAKE SLOW TO FAST
70
GOBO 1 SHAKE SLOW TO FAST
65
GOBO 13
60
GOBO 12
55
GOBO 11
50
GOBO 10
45
GOBO 9
40
GOBO 8
35
GOBO 7
30
GOBO 6
25
GOBO 5
20
GOBO 4
15
GOBO 3
10
GOBO 2
5
GOBO 1
0
WHITE
3.3 PRISM INSERTION - channel 8
BIT
EFFECT
128-255
PRISM INSERTED
0-127
PRISM EXCLUDED
3.4 PRISM ROTATION - channel 9
BIT
EFFECT
255
FAST ROTATION
……
……
192
SLOW ROTATION
191
SLOW ROTATION
……
……
128
FAST ROTATION
0-127
POSITION
3.5 PAN - channel 1
3.6 PAN FINE - channel 2
3.7 TILT - channel 3
3.8 TILT FINE - channel 4
3.9 LAMP CONTROL & RESET - channel 12
BIT
EFFECT
Remark
200-255
COMPLETE RESET
Reset is activated passing through the unused range and
staying 5 seconds.
150-199
PAN/TILT RESET
100-149
Reset small motors
80-99
UNUSED RANGE
