afx light BEAM1R User Manual

© Copyright LOTRONIC 2016 BEAM1R Page 7
2.5 Advanced interface
In hear to set a password, to prevent the non-specialize person to faulty operate. Default password is “UP DOWN
UP DOWN”. Press “Enter” to verify the password
Option
Instruction
Y Hall state
0 means the magnet closure, 1 means the magnet stagger
Color wheel hall state
0 means the magnet closure, 1 means the magnet stagger
Gobo wheel hall state
0 means the magnet closure, 1 means the magnet stagger
X coding disc state
2digit, each digit corresponding to the photoelectricity switch
on the coding disc
Y coding disc state
2digit, each digit corresponding to the photoelectricity switch
on the coding disc
X coding disc step
value
Running in positive direction, the step value adding, Running
in negative direction, the step value reduced
Y coding disc step
value
Running in positive direction, the step value adding, Running
in negative direction, the step value reduced
Reset calibration
X calibration
X Fine
Adjustment
range:-128~+1
27, +0 shows
no adjustment
Y calibration
Y Fine
Color wheel calibration
Color wheel fine
Gobo wheel calibration
Gobo wheel fine
Prism zoom calibration
Prism zoom fine
Maximum lighting hour
0-9999hours， The alarm sounded once over the maximum
lamp lighting hour
Reset lighting hour
After clear the lamp light hour, timer reset
3. DMX Channels
Channel
Value
Function
1
0---255
PAN
2
0---255
PAN FINE
3
0---255
TILT
4
0---255
TILT FINE
5
0---255
PAN-TILT Speed
6
0---4
color1
5---9
color1+color2
10---14
color2
15---19
color2+color3
20---24
color3
25---29
color3+color4
30---34
color4
35---39
color4+color5
40--44
color5
