AGA marvel MPRO6DZE - Dimensions for 6 SDZE Glass Door; 6 SDZE Unit Dimensions; 6 SDZE Rough-In Opening; 6 SDZE Electrical Requirements

* Depth dimension may vary depending on
each individual installation.
Electrical Requirements: A grounded 115 volt, 15
amp dedicated circuit is required.
Power outlet can be located in the back wall
behind unit. Add 1" to depth for thickness of plug,
or recess outlet 1" into the wall. Power outlet
can also be installed in adjacent cabinetry with a
cutout for routing of power cord. Follow all local
building codes when installing electrical and unit.
Product weight = 136 lbs. (61.8 kg.)
ROUGH IN OPENING DIMENSIONS FOR 6SDZE GLASS DOOR
DIMENSIONS FOR 6SDZE GLASS DOOR
9
** Minimum rough in opening required is to be
larger than the adjusted height of the cabinet.
24" (61 cm)
*24" (61 cm)
standard cabinet
depth
** 34
1
⁄8" to 35
1
⁄8"
(86.7 to 89.2cm)
23
7
⁄8"
(60.7cm)
3" to 4"
(7.6 to 10.2cm)
46
1
⁄2"
(118.1cm)
33
7
⁄8" to 34
7
⁄8"
(86.1 to 88.6cm)
21
9
⁄16"
(54.8cm)
23
5
⁄8"
(60cm)
25
9
⁄16"
(65.0cm)
25
21
⁄32"
(65.2cm)
