AGA Ellesmere Standard Gas Stove 11
2.3 Control Overview
DO NOT USE RECHARGEABLE BATTERIES IN THIS STOVE – WE RECOMMEND YOU USE
DURACELL ALKALINE BATTERIES ONLY
Batteries – Remote Control handset – comes fitted in the remote
▪ 1 x 9 V (Alkaline Duracell recommended). – initially supplied with the stove
▪ Low battery indicator on handsets with display.
▪ Battery replacement is recommended after 2 years maximum
Batteries – Receiver (Stove Controller) – Rear Battery Pack – supplied loose inside the stove
The stove is fitted with a simple lift out battery pack located at the rear of the stove – Fully
detailed later in this manual – therefore do not attempt to fit batteries into the actual receiver unit
(which is fitted inside the stove body in a silver heat proof pocket), as this will cause permanent
damage and void your warranty
▪ 4 x 1.5 V “AA” required (Alkaline Duracell recommended).- initially supplied with the stove
▪ Low battery indication: frequent beeps for 3 seconds when motor turns.
▪ An AC Mains Adapter may be used instead of batteries – Option Extra
▪ If NOT USING a mains adapter, battery replacement is recommended at the beginning of each
heating season. Which are fitted into the rear removable Battery pack
Only the AGA approved - AC Mains Adapter can be used. Use of other adaptors can render the
system inoperable and cause permanent damage which is not covered by the warranty
2.3.2 Remote Control
Display on the Remote Control explained
Please note – the following 3 functions are not applicable to this stove, Fan, Solenoid Valve & Light Dimmer
Fan operation
Modes of operation
(page 17)
Solenoid
Valve/Burner
OPEN and CLOSE
(page 17)
Program timer setting
(page 19)
Light/Dimmer operation
(page 17)
ON/OFF Temperatures setting
(page 18)
°C/24 hour or °F/12
hour Clock setting
(page 18)
