40 AGA Ellesmere Standard Gas Stove
5.0 Technical Data - Product Identification Number: 0359CR0001253
Ellesmere Natural Single Burner
Gas Type
Natural Gas - (G20, I2H & I2E)
Supply Pressure
20 mbar
Nominal Heat Input Gross (Hs)
6.0 kW
Nominal Heat Input Nett (Hi)
5.4 kW
Consumption
0.56 m³/hr
Burner Pressure (Hot)
14.0 mbar
Pilot
446.1385.44
Efficiency Class
1
Nox Class
5
Using the AGA Mertik GV60 valve and G9R Remote
Maximum High Heat Output 4.37 kW
This CE plate is found at the back of the stove at the bottom
The Aluminium serial plate for the stove is found if you open the front door and it is on the left hand side
above the bottom hinge mount. It is a small aluminium plate with a number printed onto it
