42 AGA Ellesmere Standard Gas Stove
5.1 Parts List Details
REF NO
QTY
DESCRIPTION
REF NO
QTY
DESCRIPTION
1
1
GA5-01 Main Stove Body
27
4
Glass Clip
2
2
N/A
28
1
100mm Blanking Plate AGA
3
1
AGA Stoves Cast Door
29
1
150mm Blanking Plate AGA
4
1
Inner Glass Frame
30
1
Delayed Ignition Flap Gasket AGA
5
2
Glass Bracket Folding AGA
31
2
Ø6 X 50mm Hinge Pin
6
1
Lock Roller
32
2
M6 X 25mm Ø8mm Shoulder Bolt
7
1
M8 x 30mm Dome Socket Screw
33
1
A5 G Glass Inner Frame
8
1
AGA Cast Handle
34
1
CE Plate
9
1
N/A
35
1
M6 x 20mm Countersunk Socket Screw
10
1
Stove Lid
36
1
AGA Cast Handle Sleeve
11
1
150mm - Air Inlet Flue Collar
37
1
M6 X 30mm Countersunk Socket Screw
12
1
100mm – Exhaust Outlet Flue Collar
38
21
M5 X 15mm Cap Socket Screw
13
1
Control Box Housing
39
10
M5 X 20mm Cap Socket Screw
14
1
Inner Removable Baffle Plate - Lift out
40
4
M6 X 20mm Cap Socket Screw
15
1
Front Shelf
41
23
M5 Spring Washer
16
1
A5 Burner Assembly – Metalwork Only
42
4
M5 X 8mm Cap Socket Screw
17
1
A5 G Grate B - Front
43
11
M5 Nut
18
1
A5 G Grate A - Rear
44
2
A5 G Glass Gasket
19
1
Delayed Ignition Flap Folding AGA
45
1
A4 Glass Gasket
20
1
GA5 Rear Heat Shield
46
1
4 x AA Battery Holder
21
1
Battery Housing
47
2
Ø3.2 X 6mm Steel Rivet
22
1
Z5 Pilot Shield Lower
48
1
N/A
23
1
Z5 Pilot Shield Upper
49
1
N/A
24
1
5G 2T Thermocouple Guard
50
2
100mm Flue Seal AGA 100mm
25
1
A5 G Inner Glass Panel
51
2
100mm Flue Seal AGA 150mm
26
1
A4 Door Glass Panel
52
1
Insulating Wrap
Gas Burner & Controller - Spare Parts
Part No
QTY
DESCRIPTION
Part No
QTY
DESCRIPTION
70001
1
Ceramic Log Pack
70010
1
Injector LPG
70002
1
Ember Pack
70011
1
Injector Natural
70003
1
Remote Handset
70012
1
Thermocouple
70004
1
Receiver Controller Unit
70013
1
Electrode Lead
70005
1
Gas Valve GV60 Assembly LPG
70014
1
Electrode
70006
1
Gas Valve GV60 Assembly Natural
70015
1
Pilot Assembly LPG
70007
1
Complete Burner Assembly LPG
70016
1
Pilot Assembly Natural Gas
70008
1
Complete Burner Assembly Natural
70017
1
GV60 Wiring Loom
70009
1
AGA Approved Mains Adapter
70018
1
Battery Box
70019
1
500mm 12v Extension Lead for
Battery box
