AGA Ellesmere Standard Gas Stove 29
Flue Systems
The Ellesmere range of balanced gas stoves are approved only for use with the AGA approved 100/150
concentric flue system
The AGA approved flue is manufactured by Poujoulat under the Duo Gas 100/150 range of Stainless
Steel concentric flues and is available in Matt black finish or Stainless Steel finish
AGA has put together the following 4 X Flue kits in association with Poujoulat
Flue Kit Ref:
Contents: see overleaf for full details
AGA Part Number
Flue Kit 1 – Black Finish
450mm flue pipe, 90° elbow & horizontal terminal
AE4M 531083
Flue Kit 1 – S/Steel Finish
450mm flue pipe, 90° elbow & horizontal terminal
AE4M 531084
Flue Kit 2 – Black Finish
450 & 950mm flue pipe, 90° elbow & horizontal terminal
AE4M 531085
Flue Kit 2 – S/Steel Finish
450 & 950mm flue pipe, 90° elbow & horizontal terminal
AE4M 531086
Flue Kit 3 – Black Finish
Snorkel terminal flue pipe adjustable – Rear Exit Only
AE4M 531087
Flue Kit 4 – Black Finish
Renovation kit - to fit into an existing Chimney opening
AE4M 531088
These kits can either be purchased directly from AGA Spares or directly from Poujoulat. The AGA
version has been manufactured in stainless steel & painted black in line with the finish on the stoves
All of the AGA Ellesmere balanced flue gas stoves are fitted with flue collars to fit the Poujoulat 100/150
Duo gas system. Please do not attempt to fit other concentric flue pipes to this flue collar as they will not
be a perfect gas tight match. This will void any warranty and would be deemed as an unauthorised
installation by AGA and would not meet Building Regulations requirements. Only a registered Gas Safe
engineer can install the AGA stove and flue system
The Poujoulat black is the nearest black colour match to the AGA heat proof paint used on the stoves.
Please note there can be slight colour and shade variances between the stove and the flue
3.5.6 Horizontal Wall Vent Termination type C
11
Flue sizing: Ø100/150 Flue Connector on Appliance is only for Poujoulat Duo Gas
Maximum pipe extension, for outside wall (H) = 1 X Vertical Pipe Rise (V).
Maximum Permissible run (H) see table below.
Vertical Flue Rise
(V) metres
Max. Horizontal Flue Run, (H) m
for Ø100/150 flue
0.5
0.5
1
1
1.5
1.5
2
2
2.5
2.5
3
3
3.5
3.5
4
4
4.5
4.5
5
5
5.5
5.5
6.5
6.5
7
7
7.5 and over
7.5
Minimum Vertical Flue Height: 0.5m
