8 AGA Ellesmere Standard Gas Stove
Fitting the Rear Support Chain – The Position of the Chain
Drilling the Flue for a Locking Screws
Picture showing the stove from the front
Picture showing the stove from the side with
the support chain fitted to a distance of
350mm. This is the minimum distance to a
combustible wall
Picture showing the stove from the top view
with the support chain fitted to a distance of
350mm. This is the minimum distance to a
combustible wall
As a mandate we require the flue pipe once finally fitted
(regardless of whether the flue exits from the top of the
stove or the rear of the stove to be drilled from either
side into the flue collar and a self-tapping screw (size
No. 8 x 10mm long – pan head stainless steel posi
drive) - one each side to be screwed into place so the
flue pipe cannot be pulled off the flue collar.
Refer to full instructions on previous page
