AGFA SnapScan - Transparency Option Specifications

Appendix D — Technical information 54
Options: Transparency option
Document feeder option
Interface: SCSI-2 interface, 25-pin and 50-pin SCSI-
connector
Transmission speed: 2 Mb/s
Environment:
- operating temperature: 10 °C to 40 °C (50 F to 104 F)
- relative humidity: 20% to 85%
- surrounding space: 10 cm (4 '') on each side, 15 cm (6 '') at the
rear side
Transparency option specifications
System: Moving light source
Maximum resolution: 300 dpi horizontal x 600 dpi vertical
Scanning area: Maximum 203 mm x 254 mm (8 '' x 10 '')
Lamp: fluorescent
Power supply: from the scanner
Interface: 15-pin cable with connector to scanner
Dimensions:
- length: 516 mm (20,3 '')
- width: 330 mm (13 '')
- height: 58 mm (2,3 '')
- weight: 4.7 kg (10.4 lb)
Environment:
- operating temperature: 10 °C to 40 °C (50 F to 104 F)
- relative humidity: 20% to 85%
- surrounding space: 10 cm (4 '') on each side, 15 cm (6 '') at the
rear side
