13
Relay / Aux.
Figure 15 Relay / Aux.
PIN Function
1
2
R1
3
4
R2
6
5
9
R3
8
7
10
R4
11
12
13
14
15
AUX 1
A-GND
AUX 2
A-GND
D-GND
