114
Chapter 6: Replacing Assemblies
CAUTION: Turn off the instrument before installing, removing, or replacing a module in the
instrument.
CAUTION: Electrostatic discharge can damage electronic components. Use grounded wriststraps
and mats when performing any service to this module.
Tools Required
• A T10 TORX screwdriver is required to remove screws connecting the probe cables
and screws connecting the back panel.
To remove the module
Instructions for removing or installing the module into the mainframe can be
found in the installation guide for the mainframe.
If you don’t have the installation guide for your mainframe, you can find the latest
version on the Internet at
www.agilent.com.
For example: to find the installation guide for a 16700B mainframe, go to
www.agilent.com and enter 16700B installation guide in the quick search box. Then
scroll down to Manuals, Guides & Notifications
to find the 16700B-Series Logic
Analysis Systems Installation Guide.
