Agilent Technologies 33120A Service Guide

33120-66502 – Display and Keyboard PC Assembly
Reference Agilent Part Mfr. Mfr. Part
Designator Number Qty Part Description Code Number
C1101 0160-5945 3 CAP-FXD 0.01 uF 50 V 04222 08055C103KAT A
C1102-1103 0180-3751 10 CAP-FXD 1 uF 35 V TA S0545 NRS105M35R8
C1104 0160-6497 3 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C1105 0160-5947 CAP-FXD 1000 pF 50 V 04222 08055C102KAT A
C1201-1203 0160-6497 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C1301-1302 0160-5947 CAP-FXD 1000 pF 50 V 04222 08055C102KAT A
C1303-1304 0160-5945 CAP-FXD 0.01 uF 50 V 04222 08055C103KAT A
C1305-1310 0160-6497 CAP-FXD 0.1 uF 25 V A 04222 12065C104KAT A
CR1101 1906-0291 1 DIODE- 70 V 100 MA 04713 MBAV99
CR1102 1906-0395 1 DIO SIG 2X SOT143L 75V 215MA 2PF 25403 BAS28
CR1105 1902-1542 1 DIODE-ZNR 6.2V 5% TO-236 (SOT-23) 04713 BZX84C6V2
J1301 34401-61602 1 DISPLAY CABLE ASSY, 8.8L 28480 34401-61602
L1301 9170-1431 1 SHIELDING CORE, BEADS 28480 9170-1431
M1301 33120-00611 1 SHIELD-ESD 28480 33120-00611
R1101 0699-1399 2 RESISTOR 23.7K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R1102 0699-1391 4 RESISTOR 10K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R1103-1106 0699-1344 4 RESISTOR 10 +-1% .125 W TKF TC=0+-100 28480 0699-1344
R1107 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R1108 0699-1378 1 RESISTOR 2.61K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R1109 0699-1435 1 RESISTOR 681 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R1301-1304 0699-1423 4 RESISTOR 215 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R1305-1306 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R1307-1308 0699-1330 2 RESISTOR 100K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R1309 0699-1399 1 RESISTOR 23.7K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
S1119 0960-0892 ROTARY ENCODER 28480 0960-0892
U1101 33120-88813 1 87C51 PROG 28480 33120-88813
U1102 1826-1402 1 IC-V RGLTR-FXD-POS 4.8/5.2V 8-P-SOIC PKG 04713 MC78L05ACD
U1103 1826-2264 1 IC-PWR MGT-UND-V-SEN 8 PINS P-SOIC PKG 04713 MC34064D-5
U1201 1820-5562 1 74HC02-GATE, QUAD 2-INPUT NOR INPUT 01295 SN74HC02D
U1202 1820-4966 1 IC-FF CMOS/74HC D-TYPE POS-EDGE-TRIG 01295 SN74HC74D
U1203 1820-5330 1 IC-INTERFACE DRIVER BIPOLAR DISPLAY 01295 SN75518FN
U1204 33120-89301 1 VACUUM FLUORESCENT DISPLAY 28480 33120-89301
U1301 1826-1528 1 IC-COMPARATOR LP QUAD 14 PIN PLSTC-SOIC 27014 LM339M
U1302 1820-6756 1 IC-SHIFT-REGISTER CMOS/74HC BIDIR 04713 MC74HC299D
Y1101 0410-4009 1 CERO-RES 12 MHZ +1-0.8% 28480 0410-4009
Chapter 7 Replaceable Parts
33120-66502 – Display and Keyboard PC Assembly
124
