33120A Mainframe
Reference Agilent Part Mfr. Mfr. Part
Designator Number Qty Part Description Code Number
A1 33120-66521 1 MAIN PC ASSEMBLY 28480 33120-66521
A2 33120-66502 1 DISPLAY AND KEYBOARD PC ASSEMBLY 28480 33120-66502
B1 3160-0847 1 FAN-TBAX 12V 5.3-CFM NOM 11855 DFB0412L-SG
CBL1-CBL2 33120-61601 2 CABLE BNC 28480 33120-61601
CBL4 RS232-61601 1 RS-232 CABLE 28480 RS232-61601
CD1 33250-13603 1 AGILENT INTUILINK ARB SOFTWARE CD 28480 33250-13603
CVR1 33120-84131 1 COVER 28480 33120-84131
F1 2110-0458 1 FUSE-500 MAT 75915 239.500
FRM1 33120-80111 1 CHASSIS 28480 33120-80111
HDW1 0380-1820 1 SPACER, .438 IN LG, .280 IN OD 28480 0380-1820
HDW2 0535-0154 1 NUT-HEX SGL-CHAM M9.0 X 0.75 2MM-THK 11239 3-9-03
HDW3 3050-1547 1 WASHER-FL MTLC 9.0 9.2-MM-ID 14-MM-OD AL 11239 4-9-01
HDW4 34401-88304 1 REAR PANEL 28480 34401-88304
KIT1 34401-86010 1 BUMPERS (FRNT/REAR) & POWER MOD CVR 28480 34401-86010
KYC1 33120-87411 1 FRONT-PANEL KNOB 28480 33120-87411
KYC2 34401-43711 1 PUSH-ROD, POWER-ON 28480 34401-43711
KYC3 34401-45011 1 CARRYING HANDLE 28480 33120-45011
MP2 33120-81911 1 FRONT-PANEL KEYPAD 28480 33120-81911
PNL1 33120-40211 1 FRONT-PANEL/BEZEL ASSEMBLY 28480 33120-40211
PS1 33120-86201 1 POWER-MODULE/FUSE & FUSE DRWR 28480 33120-86201
SCR1-SCR7 0515-0433 7 SCREW-M4 X 8MM LG PAN-HD 28480 0515-0433
SCR8-SCR9 0624-0862 2 SCREW-TPG .750-IN-LG PAN-HD-PHL STL,1022 93907 225-44395-890
T1 9100-5090 1 TRANSFORMER-PWR 100/120/220/240V 08807 8470B45
WD1 33120-49321 1 FRONT DISPLAY WINDOW 28480 33120-49321
7
Chapter 7 Replaceable Parts
33120A Mainframe
125
