Agilent 33120A Measurement
Function OUT TERM
1
Ampl Freq Nominal Error
Q Sine wave HIGH Z 7.0 Vrms 1.00 kHz 7.0 Vrms
0.070 Vrms
Sine wave HIGH Z 5.7 Vrms 1.00 kHz 5.7 Vrms
0.057 Vrms
Sine wave HIGH Z 5.5 Vrms 1.00 kHz 5.5 Vrms
0.055 Vrms
Sine wave HIGH Z 4.4 Vrms 1.00 kHz 4.4 Vrms
0.044 Vrms
Sine wave HIGH Z 3.5 Vrms 1.00 kHz 3.5 Vrms
0.035 Vrms
Sine wave HIGH Z 2.8 Vrms 1.00 kHz 2.8 Vrms
0.028 Vrms
Sine wave HIGH Z 2.2 Vrms 1.00 kHz 2.2 Vrms
0.022 Vrms
Sine wave HIGH Z 1.7 Vrms 1.00 kHz 1.7 Vrms
0.017 Vrms
Sine wave HIGH Z 1.4 Vrms 1.00 kHz 1.4Vrms
0.014 Vrms
Sine wave HIGH Z 1.1 Vrms 1.00 kHz 1.1 Vrms
0.011 Vrms
Q Sine wave HIGH Z 0.88 Vrms 1.00 kHz 0.88 Vrms
0.0088 Vrms
Sine wave HIGH Z 0.70 Vrms 1.00 kHz 0.70 Vrms
0.0070 Vrms
Sine wave HIGH Z 0.55 Vrms 1.00 kHz 0.55 Vrms
0.0055 Vrms
Sine wave HIGH Z 0.44 Vrms 1.00 kHz 0.44 Vrms
0.0044 Vrms
Sine wave HIGH Z 0.35 Vrms 1.00 kHz 0.35 Vrms
0.0035 Vrms
Sine wave HIGH Z 0.28 Vrms 1.00 kHz 0.28 Vrms
0.0028 Vrms
Sine wave HIGH Z 0.22 Vrms 1.00 kHz 0.22 Vrms
0.0022 Vrms
Sine wave HIGH Z 0.17 Vrms 1.00 kHz 0.17 Vrms
0.0017 Vrms
Sine wave HIGH Z 0.14 Vrms 1.00 kHz 0.14 Vrms
0.0014 Vrms
Sine wave HIGH Z 0.11 Vrms 1.00 kHz 0.11 Vrms
0.0011 Vrms
Q Sine wave HIGH Z 0.088 Vrms 1.00 kHz 0.088Vrms
0.00088 Vrms
Sine wave HIGH Z 0.070 Vrms 1.00 kHz 0.070 Vrms
0.00070 Vrms
Sine wave HIGH Z 0.055 Vrms 1.00 kHz 0.055 Vrms
0.00055 Vrms
Sine wave HIGH Z 0.044 Vrms 1.00 kHz 0.044 Vrms
0.00044 Vrms
Q Sine wave HIGH Z 0.036 Vrms 1.00 kHz 0.036 Vrms
0.00036 Vrms
1
Output termination set using front panel controls. HIGH Z assumes no load on
output. 50W assumes a 50W 0.1W load on output.
Chapter 4 Calibration Procedures
AC Amplitude Verification
58
