Agilent Technologies 33120A Service Guide

Install the 50W feedthrough load between the DMM and the function
generator output. Set the function generator for each output indicated in
the table on the next page. Use a DMM to measure the ACrms output
voltage of the function generator. Compare the measured results to the
test limits shown in the table. This is a 50
W output termination test.
Agilent 33120A Measurement
Function OUT TERM
1
Ampl Freq Nominal Error
Q Sine wave
50 W
3.5 Vrms 1.0000 kHz 3.5 Vrms
 0.035 Vrms
Sine wave
50 W
2.8 Vrms 1.0000 kHz 2.8 Vrms
 0.028 Vrms
Sine wave
50 W
2.2 Vrms 1.0000 kHz 2.2 Vrms
 0.022 Vrms
Sine wave
50 W
1.7 Vrms 1.0000 kHz 1.7 Vrms
 0.017 Vrms
Sine wave
50 W
1.4Vrms 1.0000 kHz 1.4Vrms
 0.014 Vrms
Sine wave
50 W
1.1 Vrms 1.0000 kHz 1.1 Vrms
 0.011 Vrms
Q Sine wave
50 W
0.88 Vrms 1.0000 kHz 0.88 Vrms
 0.0088 Vrms
Sine wave
50 W
0.70 Vrms 1.0000 kHz 0.70 Vrms
 0.0070 Vrms
Sine wave
50 W
0.55 Vrms 1.0000 kHz 0.55 Vrms
 0.0055 Vrms
Sine wave
50 W
0.44 Vrms 1.0000 kHz 0.44 Vrms
 0.0044 Vrms
Sine wave
50 W
0.35 Vrms 1.0000 kHz 0.35 Vrms
 0.0035 Vrms
Sine wave
50 W
0.28 Vrms 1.0000 kHz 0.28 Vrms
 0.0028 Vrms
Sine wave
50 W
0.22 Vrms 1.0000 kHz 0.22 Vrms
 0.0022 Vrms
Sine wave
50 W
0.17 Vrms 1.0000 kHz 0.17 Vrms
 0.0017 Vrms
Sine wave
50 W
0.14 Vrms 1.0000 kHz 0.14 Vrms
 0.0014 Vrms
Sine wave
50 W
0.11 Vrms 1.0000 kHz 0.11 Vrms
 0.0011 Vrms
Sine wave
50 W
0.088Vrms 1.0000 kHz 0.088Vrms
 0.00088 Vrms
Sine wave
50 W
0.070 Vrms 1.0000 kHz 0.070 Vrms
 0.00070 Vrms
Sine wave
50 W
0.055 Vrms 1.0000 kHz 0.055 Vrms
 0.00055 Vrms
Sine wave
50 W
0.044 Vrms 1.0000 kHz 0.044 Vrms
 0.00044 Vrms
Q Sine wave
50 W
0.035 Vrms 1.0000 kHz 0.035 Vrms
 0.00035 Vrms
Sine wave
50 W
0.028 Vrms 1.0000 kHz 0.028 Vrms
 0.00028 Vrms
Sine wave
50 W
0.022 Vrms 1.0000 kHz 0.022 Vrms
 0.00022 Vrms
Sine wave
50 W
0.018 Vrms 1.0000 kHz 0.018 Vrms
 0.00018 Vrms
1
Output termination set using front panel controls. HIGH Z assumes no load on
output. 50W assumes a 50W  0.1W load on output.
4
Chapter 4 Calibration Procedures
AC Amplitude Verification
59
