3
Display
• Bright, easy-to-read, vacuum
fluorescent display
• 16 character alpha-numeric display
to easily read data, messages, and
commands
Standard function/range keys
• Simple to use, for bench
measurements of dcV, acV, ohms,
current, frequency and period
• Select autorange or manual ranging
Menu command keys
• Immediate access to eight common
commands
• Shifted keys allow simple access to
complete command menu
Numeric/user keys
• Numeric entry for constants and
measurement parameters
• Shifted keys (f0 through f9) access
up to ten user-defined setups
Volts/ohms/ratio terminals
• Gold-plated tellurium copper for
minimum thermal emf
• 2-wire or 4-wire ohms measurements
• dc/dc or ac/dc ratio inputs
Current measurement terminals
• Easy fuse replacement with fuse
holder built into terminal
Guard terminal and switch
• For maximum common mode noise
rejection
Front-rear terminal switch
• Position selects front or rear
measurement terminals
Access speed and accuracy
through a powerful, convenient front panel
External output:
• Programmable TTL output pulse with
5
modes for flexible system interface
• Defaults to a voltmeter complete pulse
External trigger input
Rear input terminals
for convenient
system use
GPIB interface connector
