5-2
Making Measurements
By now you are familiar with the Vertical/Analog, Horizontal, and Trigger
groups of the front-panel keys. You should also know how to determine
the setup of the oscilloscope by looking at the status line at the top of
the display.
We recommend you perform all of the following exercises so you become
familiar with the powerful measurement capabilities of the oscilloscope.
Concepts about the 54620/40-series Oscilloscopes
Conceptual information about the oscilloscopes is in the “MegaZoom
Concepts and Oscilloscope Operation” chapter.
This chapter is organized into the following sections starting on these pages:
Capturing Data 5-3
Math Functions 5-17
Cursor Measurements 5-31
Automatic Measurements 5-37
