3-2
Triggering the Oscilloscope
The Agilent 54620/40-series Oscilloscopes provide a full set of features
to help automate your measurement tasks, including MegaZoom
technology to help you capture and examine the stored waveforms of
interest, even untriggered waveforms. With these oscilloscopes you can:
• modify the way the oscilloscope acquires data.
• set up simple or complex trigger conditions, as needed, to capture
only the sequence of events you want to examine.
The oscilloscopes all have common triggering functionality:
• Trigger modes
Auto
Normal
Auto Level (54620-series only)
• Coupling (including high frequency and noise rejection)
•Holdoff
• Trigger Level
• External Trigger input
• Trigger types
Edge (slope)
Pulse width (glitch)
Pattern
CAN
Duration
I
2
C
LIN
Sequence
SPI
TV
USB
• Trigger Out connector
