Table 5-5. Parts List For 200 Watt A1 Main Board for Agilent Models 654xA and 664xA (continued)
Reference
Desig.
Applicable Models Agilent Part No. Description
R624 6645A 0698-6353 Resistor 50K .1%
R625 All except 6644A 0699-2246 Resistor 25K .05%
R625 6644A 0699-2248 Resistor 47.5K .05%
R626 6543A 0699-2879 Resistor 80K .05% 5PPM .1W
R626 6544A 0699-2198 Resistor 243K .05%
R626 6641A 0699-3103 Resistor l9K .05%
R626 6642A 0699-2248 Resistor 47.5K .05%
R626 6645A 0699-3104 Resistor 250K .125W
R627 6543A 0698-6614 Resistor 7.5K .1%
R627 6544A 0698-3988 Resistor 42K .1%
R627 6641A 0698-6362 Resistor 1K .1% .125W
R627 6642A 0698-6631 Resistor 2.5K .1%
R627 6645A 0698-6353 Resistor 50K .1%
R628 65/6641A-65/6645A 0698-6320 Resistor 5K .1% .125W
R629 0757-0481 Resistor 475K 1%
R630 0698-4470 Resistor 6.98K 1%
R631 0698-4014 Resistor 787 1% .125W
R632 0698-3156 Resistor 14.7K 1%
R633 0698-3162 Resistor 46.4K 1%
R635 0698-6320 Resistor 5K .1% .125W
R637 65/6643A, 65/6644A 0698-3155 Resistor 4.64K 1%
R637 65/6641A, 65/6642A, 0757-0442 Resistor l0K 1% .125W
65/6645A
R639 0698-3456 Resistor 287K 1%
R640 0698-6343 Resistor 9K .1% .125W
R641 0698-8061 Resistor 8.25K .1%
R642 0757-0442 Resistor l0K 1% .125W
R643 0698-6630 Resistor 20K .1%
R644 0698-3156 Resistor 14.7K 1%
R645 0757-0280 Resistor 1K 1% .125W
R646 0698-6977 Resistor 30K .1% .125
R647 65/6643A 0699-0211 Resistor 859 .1%
R647 65/6644A 0698-5347 Resistor 495.5 .1%
R647 65/6641A, 65/6642A 0698-8671 Resistor 273.2 1% .1
R647 65/6645A 0699-1982 Resistor l.055K .1%
R648 65/6643A 0699-0211 Resistor 859 .1%
R648 6516644A 0698-5347 Resistor 495.5 .1%
R649 0698-6320 Resistor 5K .1% .125W
R650 0698-6320 Resistor 5K .1% .125W
R651 0698-6630 Resistor 20K .1%
R652 0698-6630 Resistor 20K .1%
R653 0698-6320 Resistor 5K .1% .125W
R654 0698-0084 Resistor 2.15K 1%
R655 0698-6320 Resistor 5K .1% .125W
R656 0698-3156 Resistor 14.7K 1%
R657 65/6643A, 65/6644A 0811-3770 Resistor .05 Ohm 1%
R657 65/6641A 5080-2217 Resistor SHUNT .005 Ohms
R657 65/6642A 5080-2218 SHUNT .01 Ohms
