Agilent Technologies 655 A Series User Manual

General Information
15
Table 1-1a. Performance Specifications for Series 654xA and 655xA (continued)
Parameter Agilent Model Number and Parameter Value
Transient Response Time
< 100 µs for the output voltage to recover to its previous level (within 0.1% of the
rated voltage or 20 mV, whichever is greater) following any step change in load
current up to 50% of the rated current.
AC Input Ratings (selectable via internal switching - see Appendix B)
Nominal line voltage
100,120,220,240 Vac:
230 Vac:
Frequency range:
-13%, +6 %
-10%, +10%
47-63 Hz
Output Terminal Isolation
±240 Vdc (maximum, from chassis ground)
Notes 1: For Supplemental Characteristics, see Table 1-1b.
Table 1-1b. Supplemental Characteristics for Series 654xA and 655xA (Note 1)
Parameter Agilent Model Number and Parameter Value
Output Programming Range (maximum programmable values)
Voltage: 6541A/6551A 6542A/6552A 6543A/6553A 6544A/6554A 6545A/6555A
8.190 V 20.475 V 35.831 V 61.425 V 122.85 V
Overvoltage Protection: 6541A/6551A 6542A/6552A 6543A/6553A 6544A/6554A 6545A/6555A
8.8 V 22.0 V 38.5 V 66.0 V 132.0 V
Current: 6541A 6542A 6543A 6544A 6545A
20.475 A 10.237 A 6.142 A 3.583 A 1.535 A
6551A 6552A 6553A 6554A 6555A
51.88 A 25.594 A 15.356 A 9.214 A 4.095 A
Average Resolution
Voltage: 6541A/6551A 6542A/6552A 6543A/6553A 6544A/6554A 6545A/6555A
2 mV 5 mV 10 mV 15 mV 30 mV
Current: 6541A 6542A 6543A 6544A 6545A
6 mA 3 mA 2 mA 1 mA 0.5 mA
6551A 6552A 6553A 6554A 6555A
15 mA 7 mA 4 mA 2.5 mA 1.25 mA
Overvoltage Protection: 6541A/6551A 6542A/6552A 6543A/6553A 6544A/6554A 6545A/6555A
13 mV 30 mV 54 mV 93 mV 190 mV
Accuracy
Overvoltage Protection: 6541A/6551A 6542A/6552A 6543A/6553A 6544A/6554A 6545A/6555A
160 mV 400 mV 700 mV 1.2 V 2.4 V
Analog Programming (VP):* 6541A/6551A 6542A/6552A 6543A/6553A 6544A/6554A 6545A/6555A
0.26% +6 mV 0.26% +15 mV 0.26% +27 mV 0.26% +45 mV 0.26% +90 mV
Analog Programming (IP):* 6541A 6542A 6543A 6544A 6545A
7.6% +18 mA 7.6% +9.2 mA 1.5%+5.5 mA 1.5%+3.2 mA 1.5%+1.4 mA
6551A 6552A 6553A 6554A 6555A
7% +75 mA 7% +31 mA 7% +16 mA 7% +8 mA 7% +5 mA
Current Monitor (+IM):* 6541A 6542A 6543A 6544A 6545A
7.6% +65 mA 7.6% +32 mA 1.6% +8.1 mA 1.6% +7.1 mA 1.6% +1.8 mA
6551A 6552A 6553A 6554A 6555A
7% +730 mA 7% +400 mA 7% +120 mA 7% +80 mA 7% +75 mA
*Referenced to supply output
Note 1: For Performance Specifications, see Table 1-la.
