Agilent Technologies 655 A Series

122 Replaceable Parts
Table 5-7. Parts List For 500 Watt A1 Main Board for 655xA & 665xA (continued)
Reference
Desig.
Applicable Models Agilent Part No. Description
R619 0698-0082 Resistor 464 1% .125W
R620,621 0757-0449 Resistor 20K 1% .125W
R622 65/6651A-65/6653A,
65/6655A
0699-2246 Resistor 25K .05%
65/6654A 0699-2248 Resistor 47.5K .05%
R623 65/6651A 0699-3103 Resistor l9K .05%
65/6652A 0699-2298 Resistor 47.5K .05%
65/6653A 0699-2879 Resistor 80K .05%
65/6654A 0699-2198 Resistor 243K .05%
65/6655A 0699-3104 Resistor 250K .05%
R624 65/6651A 0698-6362 Resistor 1K .1%
65/6652A 0698-6631 Resistor 2.5K .1%
65/6653A 0698-6614 Resistor 7.5K .1%
65/6654A 0699-2198 Resistor 42K .1%
65/6655A 0698-6353 Resistor 50K .1%
R625 65/6651A-65/6653A,
65/6655A
0699-2246 Resistor 25K .05%
65/6654A 0699-2248 Resistor 47.5K .05%
R626 65/6651A 0699-3103 Resistor l9K .05%
65/6652A 0699-2248 Resistor 47.5K .05%
65/6653A 0699-2879 Resistor 80K .05% 5ppm 1W
65/6654A 0699-2198 Resistor 243K .05%
65/6655A 0699-3104 Resistor 250K .05%
R627 65/6651A 0698-6362 Resistor 1K .1%
65/6652A 0698-6631 Resistor 2.5K .1%
65/6653A 0698-6614 Resistor 7.5K .1%
65/6654A 0698-3988 Resistor 42K .1%
65/6655A 0698-6353 Resistor 50K .1%
R628 0698-6320 Resistor 5K .1% .125W
R629 0757-0481 Resistor 475K 1%
R630 0698-4470 Resistor 6.98K 1%
R631 0698-4014 Resistor 787 1% .125W
R632 0698-3156 Resistor 14.7K 1%
R633 0698-3162 Resistor 46.4K 1%
R635 0698-6320 Resistor 5K .1% .125W
R636 Not used
R637 65/6651A, 65/6652A, 0757-0442 Resistor l0K 1% .125W
65/6655A
65/6653A, 65/6654A 0698-3155 Resistor 4.64K
R639 0698-3456 Resistor 287K 1%
R640 0698-6343 Resistor 9K .1%
R641 0698-8061 Resistor 8.25K .1%
R642 0757-0442 Resistor l0K 1% .125W
R643 0698-6630 Resistor 20K .1%
R644 0698-3156 Resistor 14.7K 1%
R645 0757-0280 Resistor 1K 1% .125W
