Replaceable Parts 125
Table 5-7. Parts List For 500 Watt A1 Main Board for 655xA & 665xA (continued)
Reference
Desig.
Applicable Models Agilent Part No. Description
R715 0757-0280 Resistor 1K 1% .125W
R716 0698-0084 Resistor 2.15K 1%
R717,718 0698-3441 Resistor 215 1% .125W
R719 Not used
R720 0698-3151 Resistor 3.83K 1%
R721,722 0757-0280 Resistor 1K 1% .125W
R723,724 0698-3260 Resistor 464K 1%
R725 0698-3155 Resistor 4.64K 1%
R726 0698-3153 Resistor 3.83K 1%
R727 0757-0442 Resistor 10K 1% .125W
R728 0757-0449 Resistor 20K 1% .125W
R729 0757-0442 Resistor 10K 1% .125W
R730 0698-0084 Resistor 2.15K 1%
R731 0698-3260 Resistor 464K 1%
R732,733 0698-3155 Resistor 4.64K 1%
R734 0757-0442 Resistor l0K 1% .125W
R740,741 0698-3155 Resistor 4.64K 1%
R742 0757-0199 Resistor 21.5K 1%
R743 0757-0441 Resistor 8.25K 1%
R744 0757-0280 Resistor 1K 1% .125W
R745 0683-0475 Resistor 4.7 5% .25W
R746 0698-3162 Resistor 46.4K 1%
R747-749 0757-0199 Resistor 21.5K 1%
R750 0757-0280 Resistor 1K 1% .125W
R751 0683-0475 Resistor 4.7 5% .25W
R752 0698-3160 Resistor 31.6K 1%
R753 0757-0465 Resistor 100K 1%
R754 65/6651A, 65/6655A 0698-8816 Resistor 2.15 1%
65/6652A-65/6654A Not used
R770,771 0757-0442 Resistor l0K 1% .125W
R772 0757-0470 Resistor 162K 1%
R773 0698-6376 Resistor 200K .1%
R774 0699-1212 Resistor 19K .1%
R775 0698-6630 Resistor 20K .1%
R778-779 0811-2201 Resistor 270 5% 2W PW
R781 0686-2225 Resistor 2.2K 5% .5W
R783, 784, 65/6651A-65/6653A Not used
R786-788
R783, 784, 65/6654A, 65/6655A 8159-0005 Resistor 0 Ohms
R786-788
R785 65/6651A 0757-0405 Resistor 162 1%
65/6652A-65/6655A 0757-0397 Resistor 68.1 1%
R790 Not used
R789,791 65/6651A Not used
65/6652A-65/6655A 8159-0005 Resistor 0 Ohms
R792 Not used
R793 65/6651A-65/6653A Not used
65/6654A, 65/6655A 8159-0005 Resistor 0 Ohms
