128 Replaceable Parts
Table 5-9A. A2 GPIB Board Replaceable Parts for 664xA & 665xA (surface-mount)
This table applies to units identified on the title page of this manual. Refer to Backdating for additional units
Ref. Desig. Agilent Part No. Description
C012-105 0160-6100 Capacitor 1000pF 100V
C106 0180-3975
Capacitor 2.2µF 20 V
C107,108 0160-5961 Capacitor 22pF 5%100 V
C109-110,114, 115,121 0160-6734
Capacitor 0.047µF 20%
C122 0180-4606 Capacitor 25V
C123 0160-6497 Capacitor 1000pF 5%
C124 0180-4116
Capacitor 22µF 15 V
C125 0160-6734
Capacitor 0.047µF 20%
C126,127 0160-5959 Capacitor 33pF 5% 100V
C128 0160-4281 Capacitor 2200pF 20%
C129-134 0160-6734
Capacitor 0.047µF 20%
C135 0180-4116
Capacitor 22µF 15 V
C136 0160-5955 Capacitor 68pF 5% 100V
C137 0160-6497
Capacitor 0.1µF 50V
C138 0160-5945
Capacitor 0.01µF 50V
C139-140 0160-6734
Capacitor 0.047µF 50V
C141 0180-4116
Capacitor 22µF 20V
C142 0160-5950 Capacitor 470pF 50V
D107-110 1901-1335 Diode power rectifier
D111-112 1906-0337 Diode IN4150
D115,116 1901-1332 Diode IN5817
D119,120 1902-1634 Diode zener 18.2V 5%
F101 2110-0699 Fuse subminature 5AM, 125V
J101 1252-2320 Connector receptacle (GPIB)
J106 1251-4926 Connector receptacle (test header)
J107,108,114,115 1251-7330 Connector receptacle phone
L101 9140-1101 Inductor 470nH
P101 1251-4245 Connector plug 2-pin (ac bias)
Q101 1853-0525 Transistor PNP 2N4917
R103 0699-1391 Resistor 10K 1%
R104 0699-1384 Resistor 4.64K 1%
R105 0699-2682 Resistor 10 M 5%
R106 0699-1360
Resistor 46.4Ω 1%
R107 0699-1431
Resistor 464Ω 1%
R108 0699-1415
Resistor 100Ω 1%
R109 0699-1431
Resistor 464Ω 1%
R111,114 0699-1384 Resistor 4.64K 1%
R115-117 0699-1360 Resistor 46.4 1%
R118 0699-1318 Resistor 1K 1%
R119 0699-1327
Resistor 1MΩ 1%
R120-122 0699-1384 Resistor 4.64K 1%
R123 0699-1431
Resistor 464Ω 1%
R130-133 0699-1384 Resistor 4.64K 1%
R134 0699-1432
Resistor 511Ω 5%
R135,136 0699-1384 Resistor 4.64K 1%
R137 0699-1415
Resistor 100Ω 1%
R138 0699-1432
Resistor 511Ω 5%
R139,142 0699-1384 Resistor 4.64K 1%
R143 0699-1330 Resistor 100K 1%
R144 0699-1415
Resistor 100Ω 1%
