General Information 19
Table 1-1b. Supplemental Characteristics for Series 664xA (continued)
1
Parameter All Models
Digital Port Characteristics
(see Table 1-5)
GPIB Interface Capabilities
(see Table 1-5)
Serial Link Capabilities
(see Table 1-5)
Recommended Calibration Interval:
1 year
Safety Compliance
Complies with:
Designed to comply with:
CSA 22.2 No.231,IEC 348
UL 1244
RFI Suppression (complies with):
CISPR-ll, Group 1, Class B
Dimensions
Width:
Height (including removable feet):
Depth (including safety cover):
425.5 mm (16.75 in)
88.1 mm (3.5 in)
439 mm (17.3 in)
Note 1: For Performance Specifications, see Table l-la.:
Weight
Net:
Shipping:
14.2 kg (31.4 lb)
16.3 kg (36 lb)
Output Characteristic Curve:
Notes:
l
For Performance Specifications, see Table l-la.
