Operation Verification 117
Table B-8. Operation Verification Test Parameters for Series 669xA
Test Description
Minimum Spec Results * Maximum
Spec
Measurement
Uncertainty
MODEL Agilent 6690A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-0.015 V ____________ V + 0.015 V
1.0
µV
Front Panel Display Readback Vout -22.5 mV ____________ mV Vout +22.5 mV
1.0
µV
High Voltage (15 V) V
out
14.979 V _____________V 15.021 V
56
µV
Front Panel Display Readback Vout -30 mV ____________ mV Vout +30 mV
56
µV
Current Programming and Readback
Low Current (0 A) I
out
-0.23 A ____________ A +0.23 A 15 mA
Front Panel Display Readback Iout -300 mA ____________ mA Iout +300 mA 15 mA
High Current (440 A) I
out
439.33 A ____________ A +440.67 A 461 mA
Front Panel Display Readback Iout -0.74 A ____________ A Iout +0.74 A 461 mA
MODEL Agilent 6691A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-0.030 V ____________ V + 0.030 V
1.0
µV
Front Panel Display Readback Vout -45 mV ____________ mV Vout +45 mV
1.0
µV
High Voltage (30 V) V
out
29.958 V _____________V 30.042 V
88
µV
Front Panel Display Readback Vout -60 mV ____________ mV Vout +60 mV
88
µV
Current Programming and Readback
Low Current (0 A) I
out
-0.125 A ____________ A +0.125 A 15 mA
Front Panel Display Readback Iout -165 mA ____________ mA Iout +165 mA 15 mA
High Current (220 A) I
out
219.655 ____________ A +220.345 A 311 mA
Front Panel Display Readback Iout -385 mA ____________ mA Iout +385 mA 311 mA
MODEL Agilent 6692A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-60 mV ____________ mV + 60 mV
1.7
µV
Front Panel Display Readback Vout -90 mV ____________ mV Vout +90 mV
1.7
µV
High Voltage ( 60 V) V
out
59.916 V _____________V 60.084 V
348
µV
Front Panel Display Readback Vout -120 mV ____________ mV Vout +120 mV
348
µV
Current Programming and Readback
Low Current (0 A) I
out
-65 mA ____________ mA +65 mA 1.5 mA
Front Panel Display Readback Iout -80 mA ____________ mA Iout +80 mA 1.5 mA
High Current ( 110 A) I
out
109.825 A ____________ A 110.175 A 83 mA
Front Panel Display Readback Iout -190 mA ____________ mA Iout +190 mA 83 mA
* Enter your test results in this column.
