Operation Verification 116
Table B-7. Operation Verification Test Parameters for Series 668xA (continued)
Test Description Minimum Spec Results * Maximum
Spec
Measurement
Uncertainty
MODEL Agilent 6684A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-40 mV ____________ mV + 40 mV
2.0
µV
Front Panel Display Readback Vout -60 mV ____________ mV Vout +60 mV
2.0
µV
High Voltage (40 V) V
out
39.944 V _____________V 40.056 V
590
µV
Front Panel Display Readback Vout -80 mV ____________ mV Vout +80 mV
590
µV
Current Programming and Readback
Low Current (0 A) I
out
-65 mA ____________ mA +65 mA 1.5 mA
Front Panel Display Readback Iout -90 mA ____________ mA Iout +90 mA 1.5 mA
High Current (128 A) I
out
127.807 A ____________ A 128.193 A 24.1 mA
Front Panel Display Readback Iout -218 mA ____________ mA Iout +218 mA 24.1 mA
* Enter your test results in this column.
