Agilent Technologies 6571A User Manual

Operation Verification 115
Table B-7. Operation Verification Test Parameters for Series 668xA
Test Description
Minimum Spec Results * Maximum
Spec
Measurement
Uncertainty
MODEL Agilent 6680A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-0.005 V ____________ V + 0.005 V
1.0
µV
Front Panel Display Readback Vout -7.5 mV ____________ mV Vout +7.5 mV
1.0
µV
High Voltage (5 V) V
out
4.9943 V _____________V 5.0057 V
56
µV
Front Panel Display Readback Vout -10 mV ____________ mV Vout +10 V
56
µV
Current Programming and Readback
Low Current (0 A) I
out
-0.450 A ____________ A +0.450 A 15 mA
Front Panel Display Readback Iout -600 mA ____________ mA Iout +600 mA 15 mA
High Current (875 A) I
out
873.675 A ____________ A +876.325 A 461 mA
Front Panel Display Readback Iout -1.475 A ____________ A Iout +1.475 A 461 mA
MODEL Agilent 6681A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-0.008 V ____________ V + 0.008 V
1.0
µV
Front Panel Display Readback Vout -12 mV ____________ mV Vout +12 mV
1.0
µV
High Voltage (8 V) V
out
7.9888 V _____________V 8.0112 V
88
µV
Front Panel Display Readback Vout -16 mV ____________ mV Vout +16 mV
88
µV
Current Programming and Readback
Low Current (0 A) I
out
-0.300 A ____________ A +0.300 A 15 mA
Front Panel Display Readback Iout -400 mA ____________ mA Iout +400 mA 15 mA
High Current (580 A) I
out
579.12 A ____________ A +580.88 A 311 mA
Front Panel Display Readback Iout -980 mA ____________ mA Iout +980 mA 311 mA
MODEL Agilent 6682A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-21 mV ____________ mV + 21 mV
1.7
µV
Front Panel Display Readback Vout -32 mV ____________ mV Vout +32 mV
1.7
µV
High Voltage ( 21 V) V
out
20.970 V _____________V 21.030 V
348
µV
Front Panel Display Readback Vout -42 mV ____________ mV Vout +42 mV
348
µV
Current Programming and Readback
Low Current (0 A) I
out
-125 mA ____________ mA +125 mA 1.5 mA
Front Panel Display Readback Iout -165 mA ____________ mA Iout +165 mA 1.5 mA
High Current ( 240 A) I
out
239.635 A ____________ A 240.365 A 83 mA
Front Panel Display Readback Iout -405 mA ____________ mA Iout +405 mA 83 mA
MODEL Agilent 6683A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-32 mV ____________ mV + 32 mV
1.9
µV
Front Panel Display Readback Vout -48 mV ____________ mV Vout +48 mV
1.9
µV
High Voltage ( 32 V) V
out
31.955 V _____________V 32.045 V
488
µV
Front Panel Display Readback Vout -64 mV ____________ mV Vout +64 mV
488
µV
Current Programming and Readback
Low Current (0 A) I
out
-85 mA ____________ mA +85 mA
1.5
µA
Front Panel Display Readback Iout -60 mA ____________ mA Iout +60 mA
1.5
µA
High Current (160 A) I
out
159.755 A ____________ A 160.245 A 35.6 mA
Front Panel Display Readback Iout -270 mA ____________ mA Iout +270 mA 35.6 mA
* Enter your test results in this column.
