Operation Verification 114
Table B-6. Operation Verification Test Parameters for Series 667xA (continued)
Test Description Minimum Spec Results * Maximum
Spec
Measurement
Uncertainty
MODEL Agilent 6675A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-120 mV ____________ mV + 120 mV
3.0
µV
Front Panel Display Readback Vout -180 mV ____________ mV Vout +180 mV
3.0
µV
High Voltage (120 V) V
out
119.832 V _____________V 120.168 V 1.7 mV
Front Panel Display Readback Vout -240 mV ____________ mV Vout +240 mV 1.7 mV
Current Programming and Readback
Low Current (0 A) I
out
-12 mA ____________ mA +12 mA
20
µA
Front Panel Display Readback Iout -18 mA ____________ mA Iout +18 mA
20
µA
High Current (18 A) I
out
17.97 A ____________ A +18.03 A 7.5 mA
Front Panel Display Readback Iout -36 mA ____________ mA Iout +36 mA 7.5 mA
* Enter your test results in this column.
