Agilent Technologies 6571A User Manual

Operation Verification 113
Table B-6. Operation Verification Test Parameters for Series 667xA
Test Description
Minimum Spec Results * Maximum
Spec
Measurement
Uncertainty
MODEL Agilent 6671A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-8 mV ____________ mV + 8 mV
1.6
µV
Front Panel Display Readback Vout -12 mV ____________ mV Vout +12 mV
1.6
µV
High Voltage (8 V) V
out
7.9888 V _____________V 8.0012 V
100
µV
Front Panel Display Readback Vout -16 mV ____________ mV Vout +16 mV
100
µV
Current Programming and Readback
Low Current (0 A) I
out
-125 mA ____________ mA +125 mA
50
µA
Front Panel Display Readback Iout -150 mA ____________ mA Iout +150 mA
50
µA
High Current (220 A) I
out
219.655 A ____________ A 220.345 A 92 mA
Front Panel Display Readback Iout -370 mA ____________ mA Iout +370 mA 92 mA
MODEL Agilent 6672A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-20 mV ____________ mV + 20 mV
2.0
µV
Front Panel Display Readback Vout -30 mV ____________ mV Vout +30 mV
2.0
µV
High Voltage (20 V) V
out
19.972 V _____________V 20.028 V
335
µV
Front Panel Display Readback Vout -40 mV ____________ mV Vout +40 mV
335
µV
Current Programming and Readback
Low Current (0 A) I
out
-60 mA ____________ mA +60 mA
40
µA
Front Panel Display Readback Iout -100 mA ____________ mA Iout +100 mA
40
µA
High Current (100 A) I
out
99.84 A ____________ A +100.16 A 41 mA
Front Panel Display Readback Iout -200 mA ____________ mA Iout +200 mA 41 mA
MODEL Agilent 6673A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-35 mV ____________ mV + 35 mV
2.0
µV
Front Panel Display Readback Vout -50 mV ____________ mV Vout +50 mV
2.0
µV
High Voltage ( 35 V) V
out
34.951 V _____________V 35.049 V
526
µV
Front Panel Display Readback Vout -68 mV ____________ mV Vout +68 mV
526
µV
Current Programming and Readback
Low Current (0 A) I
out
-40 mA ____________ mA +40 mA
31
µA
Front Panel Display Readback Iout -60 mA ____________ mA Iout +60 mA
31
µA
High Current ( 60 A) I
out
59.9 A ____________ A 60.1 A 25 mA
Front Panel Display Readback Iout -120 mA ____________ mA Iout +120 mA 25 mA
MODEL Agilent 6674A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-60 mV ____________ mV + 60 mV
2.2
µV
Front Panel Display Readback Vout -90 mV ____________ mV Vout +90 mV
2.2
µV
High Voltage ( 60 V) V
out
59.916 V _____________V 60.084 V 1 mV
Front Panel Display Readback Vout -132 mV ____________ mV Vout +132 mV 1 mV
Current Programming and Readback
Low Current (0 A) I
out
-25 mA ____________ mA +25 mA
21
µA
Front Panel Display Readback Iout -35 mA ____________ mA Iout +35 mA
21
µA
High Current (35 A) I
out
34.94 A ____________ A 35.06 A 15 mA
Front Panel Display Readback Iout -70 mA ____________ mA Iout +70 mA 15 mA
