8 – Language Dictionary
90
Table 8-1. Subsystem Commands Syntax
ABORt
Resets the trigger system to the Idle state
CALibrate
:CURRent
[:SOURce] [:DC] [:POSitive]
Calibrate positive output current and high current measurement range
:MEASure [:DC]
:R3
Calibrate middle current measurement range
:LOWRange
Calibrate low current measurement range
:AC
Calibrate ac current measurement circuits
:CURRent2
Calibrate output2 current
:DATE <date>
Sets and reads the calibration date
:DVM
Calibrate DVM voltage readback
:LEVel <level>
Advance to next calibration step (P1 | P2)
:PASSword <n>
Set calibration password
:RESistance
Calibrate output resistance
:SAVE
Save new cal constants in non-volatile memory
:STATE <bool> [,<n>]
Enable or disable calibration mode
:VOLTage [:DC]
Calibrate output voltage and voltage readback
:VOLTage2
Calibrate output2 voltage
DISPlay
[:WINDow]
[:STATe] <bool>
Enable/disable front panel display
:CHANnel <n>
Select the output that is displayed ( 1 | 2)
:MODE <mode>
Set display mode (NORM | TEXT)
:TEXT [:DATA] <string>
Sets the text that is displayed
FORMat
[:DATA] <type>
Specifies data type and length for all array queries
:BORDer <type>
Specifies byte order for all array queries
INITiate
[:IMMediate]
:SEQuence[<n>]
Enable the numbered trigger system sequence (1 | 2)
:NAME <name>
Enable the named trigger system sequence (TRAN | ACQ)
CONTinuous
:SEQuence1, <bool>
Enable continuous output transient triggers
:NAME TRANsient, <bool>
Enable continuous output transient triggers
INSTrument
:COUPle
:OUTPut
:STATe <state>
Couples or decouples output 1 and output 2 (NONE or ALL)
MEASure
:CURRent2?
Returns the output 2 current measurement
:VOLTage2?
Returns the output 2 voltage measurement
MEASure | FETCh
:ARRay
:CURRent [:DC]?
Returns the digitized instantaneous current
:VOLTage [:DC]?
Returns the digitized instantaneous voltage
[:SCALar]
:CURRent [:DC]?
Returns dc current
:ACDC?
Returns the total rms current (ac+dc)
:HIGH?
Returns the HIGH level of a current pulse
:LOW?
Returns the LOW level of a current pulse
:MAX?
Returns maximum current
:MIN?
Returns minimum current
