Replaceable Parts 107
Table 5-9. A5 Control Board Replaceable Parts (continued)
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS
R740,741 (Model specific)
6571A, 6671A 0757-0280 Resistor 1K 1% 0.125W
6572A, 6672A 0757-0429 Resistor 1.82K 1%
6573A, 6673A 0698-3279 Resistor 4.99K 1%
6574A, 6674A 0757-0442 Resistor 10K 1% 0.125W
6575A, 6675A 0757-0447 Resistor 16.2K 1%
R750 0698-8093 Resistor 40K 0.1% 0.1W
R752 0757-0199 Resistor 21.5K 1%
R761,762 0698-3430 Resistor 21.5 1%
R765 8159-0005
Resistor 0 Ω
R766 0698-8093 Resistor 40K 0.1% 0.1W
R767 (Model specific)
6571A-6573A,
6671A-6673A
0699-1741 Resistor 5.657K 0.1%
6574A, 6674A 0699-0055 Resistor 4.53K 0.1%
6575A, 6675A 0699-1741 Resistor 5.657K 0.1%
R768 (Model specific)
6571A, 6671A 0757-0410
Resistor 301 Ω 1% 0.125W
6572A, 6672A,
6573A, 6673A
0699-0083
Resistor 681 Ω 0.1% 0.1W
6574A, 6674A 0699-0211
Resistor 859 Ω 0.1%
6575A, 6675A 0698-7163 Resistor 2.0081K 0.1%
R769 0698-3279 Resistor 4.99K 1%
R770 (Model specific)
6571A, 6671A,
6572A, 6672A
0698-3155 Resistor 4.64K 1%
6573A, 6673A,
6574A, 6674A
0757-0429 Resistor 1.82K 1%
6575A. 6675A 0757-0419
Resistor 681 Ω 0.1% 0.125W
R785 (Model specific)
6571A, 6671A 0757-0472 Resistor 200K 1%
6572A, 6672A 0757-0473 Resistor 221K 1%
6573A, 6673A 0698-4536 Resistor 340K 1%
6574A, 6674A 0757-0471 Resistor 182K 1%
6575A, 6675A 0698-3455 Resistor 261K 1%
R790,791 0698-8093 Resistor 40K 0.1% 0.1W
R792,793 0698-6414 Resistor 1K 0.1% 0.1W F
R794,795 0698-6323
Resistor 100 Ω 0.1%
R801 0757-0447 Resistor 16.2K 1%
R802 0757-0468 Resistor 130K 1%
R803 0757-0462 Resistor 75K 1% 0.125W
R804 0757-0468 Resistor 130K 1%
R805 (Model specific)
6571A, 6671A 0699-3103 Resistor 19K 0.05%
6572A-6575A,
6672A-6675A
0699-2246 Resistor 25K 0.05%
