108 Replaceable Parts
Table 5-9. A5 Control Board Replaceable Parts (continued)
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS
R807 0698-8827 Resistor 1M 1% 0.125W
R808 0757-0407
Resistor 200 Ω 1% 0.125W
R809 (Model specific)
6571A, 6671A 0699-0489 Resistor 16.15K 0.01%
6572A, 6672A,
6573A, 6673A
0699-3103 Resistor 19K 0.05%
6574A, 6674A 0699-0489 Resistor 16.15K 0.01%
6575A, 6675A 0699-1510 Resistor 22.2K 0.05%
R810 0698-8093 Resistor 40K 0.1% 0.1W
R820,821 0757-0460 Resistor 61.9K 1%
R822,823 0698-3450 Resistor 42.2K 1%
R824,825 0757-0442 Resistor 10K 1% 0.125W
R827 0698-4123
Resistor 499 Ω 0.125W
R828 0757-0453 Resistor 30.1K 1%
R831 0757-0429 Resistor 1.82K 1%
R832 0757-0273 Resistor 3.01K 1%
R833 0698-3450 Resistor 42.2K 1%
R834 0757-0280 Resistor 1K 1% 0.125W
R835 0757-0465 Resistor 100K 1%
R836 0698-4479 Resistor 14K 1% 0.125W
R837 0698-3456 Resistor 287K 1%
R839 0699-0088 Resistor 1.2M 1%
R840 0698-8827 Resistor 1 M 1% 0.125W
R851 0698-3155 Resistor 4.64K 1%
R852 0757-0472 Resistor 200K 1%
R853 0698-3279 Resistor 4.99K 1%
R854 0683-2255 Resistor 2.2M 5% 0.25W
R855 0698-0082
Resistor 464 Ω 1% 0.125W
R860 0683-1005
Resistor 10 Ω 5% O.25W
R861 0698-4123
Resistor 499 Ω 1% 0.125W
R862 0757-0273 Resistor 3.01K 1%
R870,871 0698-3430
Resistor 21.5 Ω 1%
R880 0698-3279 Resistor 4.99K 1%
R885 0757-0283 Resistor 2K 1% 0.125W
R892 0698-3456 Resistor 287K 1%
R893 0757-0440 Resistor 7.5K 1%
R894,895 (Model specific)
6571A, 6671A 0699-3103 Resistor 19K 0.05%
6572A, 6672A 0699-2248 Resistor 47.5K 0.05%
6573A, 6673A 0699-2247 Resistor 121K 0.05%
6574A, 6575A,
6674A, 6675A
0699-2198 Resistor 243K 0.05%
R896 0698-3279 Resistor 4.99K 1%
U502 5080-2150 GAL programmed, main
U503 1826-1370 IC 365
