Table 5-10. A6 output Filter Board Replaceable Parts
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS
C901 (Model specific)
6571A, 6671A 0180-4333
Capacitor 22,000μF 16V
6572A, 6672A 0180-4381
Capacitor 20,000μF 25V
6573A, 6673A 0180-4390
Capacitor 12,000μF 45V
6574A, 6674A 0180-4372
Capacitor 7,000μF 75V
6575A, 6675A 0180-4466
Capacitor 2,100μF 150V
C902 (Model specific)
6571A. 6671A 0180-4333
Capacitor 22,000μF 16V
6572A-6575A,
6672A-6675A
(Not used)
C903 (Model specific)
6571A, 6671A 0180-4333
Capacitor 22,000μF 16V
6572A, 6672A (Not used)
6573A, 6673A 0180-4390 Capacitor 12,000pF 45V
6574A, 6674A 0180-4372
Capacitor 7,000μF 75V
6575A, 6675A 0180-4466
Capacitor 2,100μF 150V
C904 (Model specific)
6571A, 6671A 0180-4333
Capacitor 22,000μF 16V
6572A-6575A,
6672A-6675A
0180-4381
Capacitor 20,000μF 25V
C905 (Model specific)
6571A, 6671A 0180-4333
Capacitor 22,000μF 16V
6572A, 6672A 0180-4381
Capacitor 20,000μF 25V
6573A, 6673A 0180-4390
Capacitor 12,000μF 45V
6574A, 6674A 0180-4372
Capacitor 7,000μF 75V
6575A, 6675A 0180-4466 Capacitor 2,100pF 150V
C906 (Model specific)
6571A, 6671A 0180-4333
Capacitor 22,000μF 16V
6572A, 6672A 0180-4381
Capacitor 20,000μF 25V
6573A, 6673A 0160-4835
Capacitor 0.17μF l0% 50V
6574A, 6674A 0160-4834
Capacitor 0.047μF l0%
6575A, 6675A 0160-6804
Capacitor 0.047μF 250V
C907,908 (Model specific)
6571A, 6671A,
6572A, 6672A
0160-4183 Capacitor 1000pF 20%
6573A-6575A,
6673A-6675A
0160-4048
Capacitor 0.22μF 20%
C909,910 0160-4413
Capacitor 0.6μF l0%
C911,912 0160-4048
Capacitor 0.22μF 20%
C913,914 0160-4183 Capacitor 1000pF 20%
C930 (Model specific)
6571A, 6671A (Not used)
6572A-6575A,
6672A-6675A
0160-4835
Capacitor 0.1μF l0% 50V
