Replaceable Parts 111
Table 5-10. A6 output Filter Board Replaceable Parts (continued)
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS
C931 (Model Specfic)
6571A, 6671A,
6572A, 6672A
0160-5468
Capacitor 0.47µF 50V
6573A-6575A,
6673A-6675A
0160-6825
Capacitor 0.47µF 250V
D900 (Model Specific) See Main Chassis, Electrical Parts
D901 (Model specific)
6571A-6574A,
6671A-6674A
(Not used)
6575A, 6675A 1906-0404 Output rectifier
D902 (Model specific)
6571A-6574A,
6671A-6674A
(Not used)
6575A, 6675A 1901-1182 Output rectifier
D910,911 (Model specific)
6571A, 6671A (Not used)
6572A-6575A,
6672A-6675A
1901-1098 Out
F901 (Model specific)
6571A-6573A,
6671A-6673A
2110-0713 Fuse submin 10AM, 125V
6574A, 6674A 2110-0699 Fuse submin 5AM, 125V
6575A, 6675A 2110-0685 Fuse submin 7AM, 125V
F902 (Model specific)
6571A, 6571A,
6672A, 6672A
2110-0713 Fuse submin 10AM, 125V
6573A, 6673A (Not used)
6574A, 6674A 2110-0699 Fuse submin 5AM, 125V
6575A, 6675A (Not used)
L900 (Model specific) See Main Chassis, Electrical Parts
L901,902 (Model specific)
6571A, 6572A,
6671A, 6672A
(Not used)
6573A, 6673A 9170-0061 Coil toroid
6574A, 6674A 9170-1195 Coil toroid
6575A, 6675A 9170-0061 Coil toroid
L90lA (Model specific)
6571A, 6671A 9170-1040 Coil toroid
6572A, 6573A,
6672A, 6673A
(Not used)
6574A, 6674A 9170-1512 Coil toroid
6575A, 6675A 9170-0061 Coil toroid
L90lB (Model specific)
6571A, 6671A 9170-1040 Coil toroid
6572A, 6573A,
6672A, 6673A
(Not used)
6574A, 6674A 9170-1512 Coil toroid
6575A, 6675A (Not used)
To Next Page
