Agilent Technologies 6674A

112 Replaceable Parts
Table 5-10. A6 output Filter Board Replaceable Parts (continued)
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS
L903,903 (Model specific)
6571A, 6671A,
6572A, 6672A
(Not used)
6573A, 6673A 9170-1518 Coil toroid
6574A, 6674A (Not used)
6575A, 6675A 9170-1517 Coil toroid
L904A,904B (Model
specific)
6571A-6573A,
6671A-6673A
(Not used)
6574A, 6674A 9170-1512 Coil toroid
6575A, 6675A (Not used)
Q901 (Model specific)
6571A, 6671A, 1855-0834 MOSFET power
6572A, 6672A 5182-9080 MOSFET power
6573A-6575A,
6673A-6675A
1855-1003 MOSFET
Q902 (Model specific)
6571A, 6671A (Not used)
6572A, 6672A 5182-9080 MOSFET power
6573A-6575A,
6673A-6675A
1855-1003 MOSFET
Q903 (Model specific)
6571A, 6671A
6572A, 6672A,
(Not used)
6573A-6575A,
6673A-6675A
1855-1003 MOSFET
Q910 (Model specific)
6571A, 6671A (Not used)
6572A-6575A,
6672A-6675A
1853-0510 Transistor PNP
R901-904 0757-0489
Resistor 10 Ω 5% 0.25W
R905,906 0683-0475
Resistor 4.7 Ω 5% 0.25W
R907 (Model specific)
6571A, 6671A 06671-20001 Shunt current 250A
6572A, 6672A 06672-20001 Shunt current 125A
6573A, 6673A 06673-20001 Shunt current 75A
6574A, 6674A 06674-20001 Shunt current 50A
6575A, 6675A 06675-20001 Shunt current 20A
R908 0683-2755 Resistor 2.7M 5% 0.25W
R909 (Model specific)
6571A, 6671A 0698-3311
Resistor 51 Ω 5% 2W MO
6572A, 6672A 0698-3630
Resistor 300 Ω 5% 2W Mo
6573A, 6673A 0764-0016 Resistor 1K 5% 2W Mo
6574A, 6674A 0683-2755 Resistor 3K 5% 2W Mo
6575A, 6675A 0698-3646 Resistor 12K 5% 2W Mo
