Operation Verification 109
Table B-4. Operation Verification Test Parameters for Series 664xA
Test Description
Minimum Spec Results * Maximum
Spec
Measurement
Uncertainty
MODEL Agilent 6641A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-5 mV ____________ mV + 5 mV
2.0
µV
Front Panel Display Readback Vout -6.0 mV ____________ mV Vout +6.0 mV
2.0
µV
High Voltage (8 V) V
out
7.990 V _____________V 8.010 V
88
µV
Front Panel Display Readback Vout -11.6 mV ____________ mV Vout +11.6 mV
88
µV
Current Programming and Readback
Low Current (0 A) I
out
-26 mA ____________ mA +26 mA
153
µA
Front Panel Display Readback Iout -18 mA ____________ mA Iout +18 mA
153
µA
High Current (20 A) I
out
19.944 A ____________ A +20.056 A 2.7 mA
Front Panel Display Readback Iout -48 mA ____________ mA Iout +48 mA 2.7 mA
MODEL Agilent 6642A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-10 mV ____________ mV + 10 mV
2.0
µV
Front Panel Display Readback Vout -15 mV ____________ mV Vout +15 mV
2.0
µV
High Voltage (20 V) V
out
19.978 V _____________V 20.022 V
335
µV
Front Panel Display Readback Vout -29 mV ____________ mV Vout +29 mV
335
µV
Current Programming and Readback
Low Current (0 A) I
out
-13 mA ____________ mA +13 mA
20
µA
Front Panel Display Readback Iout -9.1 mA ____________ mA Iout +9.1 mA
20
µA
High Current (10 A) I
out
9.972 A ____________ A +10.028 A 3.1 mA
Front Panel Display Readback Iout -24.1 mA ____________ mA Iout +24.1 mA 3.1 mA
MODEL Agilent 6643A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-15 mV ____________ mV + 15 mV
2.0
µV
Front Panel Display Readback Vout -25 mV ____________ mV Vout +25 mV
2.0
µV
High Voltage ( 35 V) V
out
34.964 V _____________V 35.036 V
525
µV
Front Panel Display Readback Vout -50 mV ____________ mV Vout +50 mV
525
µV
Current Programming and Readback
Low Current (0 A) I
out
-6.7 mA ____________ mA +6.7 mA
16
µA
Front Panel Display Readback Iout -5 mA ____________ mA Iout +5 mA
16
µA
High Current ( 6 A) I
out
5.985 A ____________ A 6.015 A 1.1 mA
Front Panel Display Readback Iout -14 mA ____________ mA Iout +14 mA 1.1 mA
MODEL Agilent 6644A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-26 mV ____________ mV + 26 mV
2.0
µV
Front Panel Display Readback Vout -40 mV ____________ mV Vout +40 mV
2.0
µV
High Voltage ( 60 V) V
out
59.938 V _____________V 60.062 V
845
µV
Front Panel Display Readback Vout -82 mV ____________ mV Vout +82 mV
845
µV
Current Programming and Readback
Low Current (0 A) I
out
-4.1 mA ____________ mA +4.1 mA
16
µA
Front Panel Display Readback Iout -3 mA ____________ mA Iout +3 mA
16
µA
High Current (3.5 A) I
out
3.491 A ____________ A +3.509 A
500
µA
Front Panel Display Readback Iout -8.3 mA ____________ mA Iout +8.3 mA
500
µA
* Enter your test results in this column.
