Operation Verification 110
Table B-4. Operation Verification Test Parameters for Series 664xA (continued)
Test Description Minimum Spec Results * Maximum
Spec
Measurement
Uncertainty
MODEL Agilent 6645A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-51 mV ____________ mV + 51 mV
2.0
µV
Front Panel Display Readback Vout -80 mV ____________ mV Vout +80 mV
2.0
µV
High Voltage (120 V) V
out
119.877 V _____________V 120.123 V 1.7 mV
Front Panel Display Readback Vout -164 mV ____________ mV Vout +164 mV 1.7 mV
Current Programming and Readback
Low Current (0 A) I
out
-1.7 mA ____________ mA +1.7 mA
16
µA
Front Panel Display Readback Iout -1.3 mA ____________ mA Iout +1.3 mA
16
µA
High Current (1.5 A) I
out
1.496 A ____________ A +1.504 A
188
µA
Front Panel Display Readback Iout -3.5 mA ____________ mA Iout +3.5 mA
188
µA
* Enter your test results in this column.
