Operation Verification 111
Table B-5. Operation Verification Test Parameters for Series 665xA
Test Description
Minimum Spec Results * Maximum
Spec
Measurement
Uncertainty
MODEL Agilent 6651A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-5 mV ____________ mV + 5 mV
2.0
µV
Front Panel Display Readback Vout -6.0 mV ____________ mV Vout +6.0 mV
2.0
µV
High Voltage (8 V) V
out
7.990 V _____________V 8.010 V
88
µV
Front Panel Display Readback Vout -11.6 mV ____________ mV Vout +11.6 mV
88
µV
Current Programming and Readback
Low Current (0 A) I
out
-60 mA ____________ mA +60 mA
150
µA
Front Panel Display Readback Iout -67 mA ____________ mA Iout +67 mA
150
µA
High Current (50 A) I
out
49.865 A ____________ A +50.135 A 10.7 mA
Front Panel Display Readback Iout -142 mA ____________ mA Iout +142 mA 10.7 mA
MODEL Agilent 6652A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-10 mV ____________ mV + 10 mV
2.0
µV
Front Panel Display Readback Vout -15 mV ____________ mV Vout +15 mV
2.0
µV
High Voltage (20 V) V
out
19.978 V _____________V 20.022 V
335
µV
Front Panel Display Readback Vout -29 mV ____________ mV Vout +29 mV
335
µV
Current Programming and Readback
Low Current (0 A) I
out
-25 mA ____________ mA +25 mA
153
µA
Front Panel Display Readback Iout -26 mA ____________ mA Iout +26 mA
153
µA
High Current (25 A) I
out
24.937 A ____________ A +25.063 A 3.5 mA
Front Panel Display Readback Iout -63.5 mA ____________ mA Iout +63.5 mA 3.5 mA
MODEL Agilent 6653A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-15 mV ____________ mV + 15 mV
2.0
µV
Front Panel Display Readback Vout -25 mV ____________ mV Vout +25 mV
2.0
µV
High Voltage ( 35 V) V
out
34.964 V _____________V 35.036 V
525
µV
Front Panel Display Readback Vout -50 mV ____________ mV Vout +50 mV
525
µV
Current Programming and Readback
Low Current (0 A) I
out
-13 mA ____________ mA +13 mA
17
µA
Front Panel Display Readback Iout -15 mA ____________ mA Iout +15 mA
17
µA
High Current ( 15 A) I
out
14.964 A ____________ A 15.036 A 6.2 mA
Front Panel Display Readback Iout -37.5 mA ____________ mA Iout +37.5 mA 6.2 mA
MODEL Agilent 6654A
Voltage Programming and Readback
Low Voltage (0 V) V
out
-26 mV ____________ mV + 25 mV
2.0
µV
Front Panel Display Readback Vout -40 mV ____________ mV Vout +40 mV
2.0
µV
High Voltage ( 60 V) Vout 59.938 V _____________V 60.062 V
845
µV
Front Panel Display Readback Vout -82 mV ____________ mV Vout +82 mV
845
µV
Current Programming and Readback
Low Current (0 A) I
out
-8 mA ____________ mA +8 mA
16
µA
Front Panel Display Readback Iout -7 mA ____________ mA Iout +7 mA
16
µA
High Current (9 A) I
out
8.978 A ____________ A +9.022 A 2.5 mA
Front Panel Display Readback Iout -20.5 mA ____________ mA Iout +20.5 mA 2.5 mA
* Enter your test results in this column.
