2 - Installation
24
Figure 2-3. Connecting the Power Cord
Output Connections
The power output terminal block has a floating output terminal connection and a floating neutral line for
the return connection. A separate earth ground terminal is located on the extreme right of the terminal
block.
Figure 2-4. Output Connections
1
2
3
5
6
4
8
7
1. GROUND CONNECTION (GRN/YEL OR GRN)
2. LINE CONNECTION (BROWN OR BLACK)
3. NEUTRAL CONNECTION (BLUE OR WHITE)
4. POWER CORD
5. CONNECTOR NUT
6. RUBBER BOOT
7. POWER SAFETY COVER
8. STRAIN RELIEF CONNECTOR
L1 L2(N)
01 01 COM COM
SENSE
!
300 VAC MAX TO
01 PHASE 1 OUTPUT CONNECTION
COM PHASE RETURN CONNECTION
GROUND CONNECTION
