Agilent Technologies 6811B User Manual

59
A
Specifications
Specifications
Table A-1 lists the specifications of the ac source. Performance specifications are warranted over the
ambient temperature range of 0 to 40
o
C. Unless otherwise noted, specifications are for a sinewave with
a resistive load at an output frequency range of 45 Hz to 1 kHz, in ac-coupled mode after a 30-minute
warmup. Refer to table A-3 for ac source operation with output frequencies from dc to 45 Hz.
Table A-1. Performance Specifications
1
Parameter Agilent 6811B Agilent 6812B Agilent 6813B
Phases:
1 1 1
Maximum Output Ratings Power (VA):
375 VA 750 VA 1750 VA
dc Power (Watts):
285 W 575 W 1350 W
rms Voltage:
300 V 300 V 300 V
dc Voltage:
± 425 V ± 425 V ± 425 V
rms Current (in real-time mode):
3.25 A 6.5 A 13 A
dc Current:
2.5 A 5 A 10 A
Repetitive peak Current
2
:
40 A 40 A 80 A
Non-repetitive peak Current
2
(inrush):
40 A 40 A 80 A
Crest Factor
2
(current):
12 6 6
Output Frequency Range
3
:
dc; 45 Hz−1 kHz
Constant Voltage Ripple rms relative to full scale:
−60 dB
and Noise
(20 kHz−10 MHz):
rms:
300 mV
Regulation: Load (rms detection mode):
0.5% of full scale
Line:
0.1% of full scale
Maximum Total Harmonic
Distortion:
0.25% at 50 Hz/60 Hz
1% worst-case 45 Hz−1 kHz
Load Power Factor
Capability:
0−1
Maximum Fixed dc Offset
Voltage (ac coupled):
100 mV
Programming Accuracy
(rms detection mode @ 25
o
C
±5
o
C), ±(% of output+offset)
rms Voltage (45−100 Hz):
(>100−500 Hz):
(>500 Hz−1 kHz):
0.15% + 0.3 V
0.5% + 0.3 V
1% + 0.3 V)
Frequency:
0.01% + 10 µHz
dc Voltage:
0.1% + 0.5 V 0.1% + 0.5 V 0.5% + 0.3 V
Measurement Accuracy
(@25
o
C ±5
o
C), ± (% of
output + offset)
rms Voltage (45−100 Hz):
(>100−500 Hz):
(>500 Hz−1 kHz):
0.03% + 100 mV
0.1% + 100 mV
0.2% + 100 mV
Frequency:
0.01% + 0.01 Hz
dc Voltage:
0.03% + 150 mV
