A - Specifications
62
Table A-2. Supplemental Characteristics (continued)
Parameter Agilent 6811B Agilent 6812B Agilent 6813B
Transient System
Phase Synchronization:
± 100 µs
Pulse Width Range:
200 µs to 4.3 x 10
seconds
Pulse/Dwell Timing Accuracy:
± 0.01%
Pulse Duty Cycle Range:
0 to 100 %
Pulse Count Range:
1 to Infinity Pulses
LIST Length:
1 to 100 steps
Minimum LIST Dwell Time:
200 µs
LIST Count Range:
1 to Infinity LIST repeats
External Trigger Response Time:
200 µs
Maximum External Trigger Rate:
1 kHz
Waveform Table Voltage Resolution:
1024 points
RS-232 Interface Capabilities
Baud Rates:
300, 600, 1200, 2400, 4800, 9600
Data Format:
7 bits even or odd parity; 8 bits without parity
Language:
SCPI (Standard Commands for Programmable Instruments),
Elgar 9012 PIP
Trig In/Trig Out Characteristics
Trig Out (HC TTL output):
V
= 0.8 max. @ 1.25 mA
V
= 3.3 V max. @ 1.25 mA
Trig In (10k pullup):
V
= 0.8 V max.
V
= 2 V max.
INH/FLT Characteristics
Maximum Ratings:
16.5 Vdc between INH terminals; FLT terminals; and from INH
terminals to chassis ground
INH Terminals:
I
= 1.25 mA max.
V
= 0.5 Vmax.
FLT Terminals:
V
= 0.8 V max.
V
= 2 V min.
tw = 100 µs min.
td = 4 ms typical
Saveable Data (nonvolatile)
Instrument States:
16 (0 to 15)
User-defined waveforms
12 (with 1024 data points in each)
List data:
1 to 100 steps (for each list function)
GPIB Interface Capabilities
Language:
SCPI, Elgar 9012 PIP
Interface:
AH1, C0, DC1, DT1, E2, LE1, PP0, RL1, SH1, SR1, TE6
Programming Time:
10 ms
Recommended Calibration Interval:
1 year
Regulatory Compliance
Listed to:
UL 3111-1
Certified to:
CSA 22.2 No. 1010-1
Conforms to:
IEC 1010
RFI Suppression Complies with:
CISPR-11, Group 1, Class A
Dimensions
Height (add 12.7 mm or 0.5 in. for feet)
132.6 mm (5.25 in.)
Width:
425.5 mm (16.75 in.)
Depth:
574.7 mm (22.6 in.)
Net Weight:
28.2 kg (62 lb) 32.7 kg (72 lb)
Shipping Weight:
31.8 kg (70 lb) 36.4 kg (80 lb)
